Herbig-Haro 49/50 (NIRCam and MIRI Image)
About This Image
Caption
NASA’s James Webb Space Telescope observed Herbig-Haro 49/50, an outflow from a nearby still-forming star, in high-resolution near- and mid-infrared light. The young star is off to the lower right corner of the Webb image.Intricate features of the outflow, represented in reddish-orange color, provide detailed clues about how young stars form and how their jet activity affects the environment around them. A chance alignment in this direction of the sky provides a beautiful juxtaposition of this nearby Herbig-Haro object (located within our Milky Way) with a face-on spiral galaxy in the distant background.
Protostars are young stars in the process of formation that generally launch narrow jets of material. These jets move through the surrounding environment, in some cases extending to large distances away from the protostar.
Like the water wake generated by a speeding boat, the arcs in this image are created by the fast-moving jet slamming into surrounding dust and gas. This ambient material is compressed and heats up, then cools by emitting light at visible and infrared wavelengths. In particular, the infrared light captured here by Webb highlights molecular hydrogen and carbon monoxide.
The galaxy that appears by happenstance at the tip of Herbig-Haro 49/50 is a much more distant spiral galaxy. It has a prominent central bulge represented in blue that shows the location of older stars. It also displays hints of “side lobes,” suggesting that this could be a barred-spiral galaxy. Reddish clumps within the spiral arms show the locations of warm dust and groups of forming stars.
There are many more galaxies at further distances in the surrounding background, including ones that shine through the diffuse infrared glow of the nearby Herbig-Haro object.
About The Object
- Object Name
- Herbig-Haro 49/50, HH 49/50
- Object Description
- Stellar Jets
- R.A. Position
- 11:05:56.2
- Dec. Position
- -77:33:31.7
- Constellation
- Chamaeleon
- Distance
- 625 light-years
- Dimensions
- Image is 2.13 arcmin across (about 0.3 light-years)
About The Data
- Data Description
- This image was created with Webb data from proposal: 6558 (M. Garcia Marin). Image processing: Joseph DePasquale (STScI).
- Instrument
- NIRCam, MIRI
- Exposure Dates
- 06 August 2024
- Filters
- NIRCam: F200W, F335M, F444W, F470N; MIRI: F770W
About The Image
- Color Info
- These images are a composite of separate exposures acquired by the James Webb Space Telescope using the NIRCam and MIRI instruments. Several filters were used to sample specific wavelength ranges. The color results from assigning different hues (colors) to each monochromatic (grayscale) image associated with an individual filter. In this case, the assigned colors are: Red: F770W, Orange: F470N, Green: F444W, Cyan: F335M, Blue: F200W
- Compass and Scale Image
-
About The Object
- Object Name
- A name or catalog number that astronomers use to identify an astronomical object.
- Object Description
- The type of astronomical object.
- R.A. Position
- Right ascension – analogous to longitude – is one component of an object's position.
- Dec. Position
- Declination – analogous to latitude – is one component of an object's position.
- Constellation
- One of 88 recognized regions of the celestial sphere in which the object appears.
- Distance
- The physical distance from Earth to the astronomical object. Distances within our solar system are usually measured in Astronomical Units (AU). Distances between stars are usually measured in light-years. Interstellar distances can also be measured in parsecs.
- Dimensions
- The physical size of the object or the apparent angle it subtends on the sky.
About The Data
- Data Description
- Proposal: A description of the observations, their scientific justification, and the links to the data available in the science archive.
- Science Team: The astronomers who planned the observations and analyzed the data. "PI" refers to the Principal Investigator.
- Instrument
- The science instrument used to produce the data.
- Exposure Dates
- The date(s) that the telescope made its observations and the total exposure time.
- Filters
- The camera filters that were used in the science observations.
About The Image
- Color Info
- A brief description of the methods used to convert telescope data into the color image being presented.
- Compass and Scale Image
- An astronomical image with a scale that shows how large an object is on the sky, a compass that shows how the object is oriented on the sky, and the filters with which the image was made.
